Product Code: ROBT 902-0096-000


GST inclusive


Availability: Backorder

Add to Wish List

The MX-28AT provides the following improvements from the previous versions:

  • New Aluminum front case
  • Decreased noise and improved protection against heat
  • Front screw threads are already threaded for easy assembly
  • Same dimensions as the previous DYNAMIXEL MX-series so all existing frames are compatible

Package Contents

Description Quantity
HORN RX28 HN07-N101 1
WASHER Thrust Washer 1
CABLE 3P Cable 200MM 1
BOLT/NUT Wrench Bolt M2.5*6 16
Wrench Bolt M2.5*8 1
Wrench Bolt M2*3 10
Nut M2.5 18

Hardware Specifications

Description Specification
Weight 77g
Dimension 35.6mm x 50.6mm x 35.5mm
Gear Ratio 193 : 1
Operational Voltage (V) 11.1 12 14.8
Stall Torque (N.m) 2.3 2.5 3.1
Stall Current (A) 1.3 1.4 1.7
No Load Speed (RPM) 50 55 67
Motor Maxon Motor
Minimum Control Angle 0.088 degrees ( x 4,096 ) = 360 degrees
Operating Modes

Actuator Mode – varying directional movement

Wheel Mode – continuous unidirectional movement
Operating Voltage 10~14.8V (Recommended voltage : 12V)
Operating Temperature -5°C ~ 80°C
Instruction Command Digital Data Packet in a Serial Bit Stream
Interface Communication Protocol Half duplex Asynchronous Serial Communication (8 bit,1 stop, No Parity)
Connector Type TTL Multi Drop type connector
ID range 254 total possible.  Values are from (0x00 – 0xFF hex)
Baud Rate 8000 bps - 4.5Mbps
Internal Sensors Position, Temperature, Load, Input Voltage, etc.

Case: Engineered Plastic

Gears: Metal
Position Sensor Contactless magnetic rotary encoder


■ Hyperlinks

Frame, Horn, Bearing Compatible Chart : Click Here

Controller Compatibility Chart : Click Here

Download Drawing : Click Here

Dynamixel SDK : Click Here

OpenCM IDE : Click Here

Software RoboPlus (R+) : Click Here

Link to e-Manual : Click Here
