Pygate is Pycom’s latest hardware tech portfolio addition.

This is a new super low-cost 8-channel LoRaWAN gateway that comes in the shape of a shield. It’s got the well-known form factor from our other shields and you can connect your much loved WiPy3, LoPy4 or a GPy to it. Hook in your Pycom development boards up and you have yourself a nifty little decentralized IoT network in one go. Pygate also fits inside the Universal IP67 Case so you don’t have to limit yourself to indoors.

Connect a WiPy3, LoPy4 or a GPy to this shield and then hook in all your other Pycom devices and you have yourself a nifty little decentralised IoT network in one go.

Check out the optional Power over Ethernet via daughter board. Coming soon


  • Dual SX1257 transceivers for a total of 8 channels support
  • Frequencies: 863-870 MHz and 902-928 MHz
  • Baseband processor: SX1308
  • Compatible with WiPy3.0, GPy and LoP4
  • Ultra-low power standby mode
  • Ethernet with PoE via the optional daughter board
  • Powered via USB, LiPo Battery and Ethernet via the optional daughter board
  • LiPo battery charging via the USB port
  • USB to serial connection for the Pycom module with auto-programming features
  • Dimensions: 65 (W) x 50 (L) x 8 (H) mm
    (Same small form factor as the Expansion Board v3.0/v3.1)
  • Fits the universal IP67 Case for outdoor use

PoE Adapter Specification

(This is optional)

  • PoE (Power Over Ethernet) with 1.5A current delivery.

  • It can provide power for the Pygate and the Pycom module attached to it.

  • 10BASE-T and 100BASE-TX Physical Layer Support

  • Auto-Negotiation: 10/100 Mbps Full- and HalfDuplex

  • Plug and play compatibility with Pygate.

  • Works transparently using the TCP/IP stack embedded into our MicroPython modules.

  • Dimensions: 21 (W) x 55 (L) x 32 (H) mm

Important Note: Pygate is not compatible with FiPy
